Spec:---------------------------
- Displacement: 3.49 cc / 0.213cu.in.
- Bore: 16.08mm / 0.633 in.
- Stroke: 17.20mm / 0.677 in.
- Output:2.65 ps / 2.61 hp / 34,000 r.p.m.
- Practical rpm range: 4,000-42,000 r.p.m.
- Weight:362g / 12.77 oz.
Standard accessories---------------------------
- Glow Plug RP7
- Venturi 7.0MM(RED)AL2
- Venturi 7.0MM(RED)AL2 Exhaust seal ring
- Dust cap set(φ3、φ16、φ18)
-
Product features
-
The crankshaft uses two tungsten counterweights. We have optimized the mass balance by reviewing the detailed dimensions.
-
The inner head has been revised. Improved low and medium speed feeling and idling performance. An O-ring is also used to reduce vibration and improve dust resistance.
-
The weight of the new outer head, compared to previous model has been reduced. Fins of outer head has been machined.
-
Equipped with 5 scavenging ports and 3 exhaust ports to meet IFMAR regulations.
-
Equipped with a double-adjust type 22E(B) GT carburetor. The new venturi is 7.0MM(RED) AL2.
-
COMBOSET comes with TB01 EFRA2042 (T-2060SC) + MB01-70 (M2003SC).
-
